Virpil VPC Universal Control Panel - #2 | Multi-Function Landing Gear Panel

Regular price
$469.00
Regular price
Sale price
$469.00
Tax included. Shipping calculated at checkout.

Vendor : Virpil

Product Type : Flight Control Panel

Sku : VPC-402

Reassurance Image
Secure Checkout
Reassurance Image
5 Star Service
Reassurance Image
Phone Support
Reassurance Image
Manufacturer Warranty

VPC Universal Control Panel #2
The Panel With a Real Landing Gear Lever.

The standout feature of the VPC Universal Control Panel #2 is a precision multi-position landing gear lever with a spring-loaded lift-to-move mechanism, swappable detent plate, aircraft gear status LEDs and a contactless digital position sensor. Add 10 customisable RGB buttons, 10 toggle switches and 3 encoder dials, all in an aircraft-grade Duralumin frame, with button inlay sticker sheets included.

Official Australian and New Zealand VIRPIL Distributor

24+total inputs
Landing gearlever, spring-loaded lift-to-move
10×customisable RGB buttons
Inlay stickersincluded
encoder dials (+ push)
10×toggle switches
Gear statusLEDs, in-transit indicator
USB + AUXstandalone or daisy chain
VIRPIL VPC Universal Control Panel #2 with landing gear lever in a flight sim cockpit
VIRPIL VPC Universal Control Panel #2 RGB buttons and toggle switches detail
VIRPIL VPC Universal Control Panel #2 landing gear lever close up
VIRPIL VPC Universal Control Panel #2 mounted in a HOTAS cockpit setup

24+ inputs. Including a real landing gear lever.

Input type Qty
Customisable RGB momentary buttons 10
Toggle switches 10
Encoder dials (+ push) 3
Multi-position landing gear lever (2 or 3 position) 1
Total inputs 24+

Every input you need, including the one that matters most.

Multi-position landing gear lever

The signature feature: a precision landing gear lever with all-metal mechanism, spring-loaded lift-to-move gate, and a VPC Digital Contactless position sensor. A swappable detent plate switches between 2-position (UP-DOWN) and 3-position (UP-OFF-DOWN) modes, with three aircraft gear status LEDs for in-transit and position indication.

10× customisable RGB momentary buttons

Ten buttons with transparent removable caps, so you can insert your own inlay stickers to label every function. RGB backlighting is fully configurable per button in the free VPC Configuration Suite. Sticker inlay sheets are included in the box.

10× toggle switches for maximum systems control

Ten toggle switches cover autopilot modes, weapon systems, avionics, navigation, engine systems and more. The high toggle count makes the CP2 a preferred choice for complex multi-role aircraft in DCS World and study-level airliners in Microsoft Flight Simulator.

3× encoder dials and gear status LEDs

Three encoder dials with push function for step-by-step control of radar range, radio frequency, countermeasure quantity and more. Three aircraft gear status LEDs mimic the real landing-gear indicators found in DCS aircraft cockpits.

Three mounting configurations

Use the included legs for standalone desktop placement, mount directly onto a VPC Desk Mount, or combine it with another Control Panel or a VPC MongoosT-50CM2 throttle to form a single unified unit. Flexible for every cockpit setup.

Standalone or AUX daisy chain

Works as a standalone USB HID device with no drivers, or AUX daisy-chains to appear as a single device alongside a VIRPIL throttle, so the throttle's mode dial multiplies your effective input count without using extra USB ports.

Aircraft-grade Duralumin build

A precision Duralumin frame and mechanics give the CP2 a solid, aircraft-grade feel built to last through the most demanding sim sessions.

VIRPIL VPC Universal Control Panel #2 full panel layout with landing gear lever, RGB buttons and toggle switches

A landing gear lever that feels real.

Lift-to-move gate, swappable detent

All-metal mechanism · contactless sensor · gear status LEDs

The multi-position landing gear lever uses an all-metal internal mechanism with a spring-loaded lift-to-move gate, preventing accidental actuation and closely mimicking the feel of a real aircraft landing gear lever. It is read by a VPC Digital Contactless position sensor for precise, reliable, wear-free input.

  • Swappable detent plate for 2-position (UP-DOWN) or 3-position (UP-OFF-DOWN) operation to suit your aircraft
  • Three gear status LEDs for visual in-transit and gear position indication
  • Spring-loaded lift-to-move gate prevents accidental gear actuation
  • VPC Digital Contactless sensor for precise, wear-free position reading

VPC Universal Control Panel #2 — full spec sheet

SKUVPC-402
Total inputs24+
RGB momentary buttons10× (transparent removable caps)
Toggle switches10×
Landing gear leverMulti-position, spring-loaded lift-to-move
Detent plateSwappable — 2-pos (UP-DOWN) or 3-pos (UP-OFF-DOWN)
Encoder dials3× (+ push)
Gear status LEDs3× aircraft gear position indicators
Gear lever sensorVPC Digital Contactless position sensor
Frame materialAircraft-grade Duralumin
Button inlay stickersIncluded
RGB lightingPer-button configurable
MountingDesktop legs, VPC Desk Mount, combined unit
ConnectivityUSB + AUX (daisy chain)
Drivers requiredNo — standard USB HID
SoftwareVPC Configuration Suite (free)
Warranty2 years (VIRPIL)
ManufacturedLithuania, EU

In the box

  • VPC Universal Control Panel #2
  • Desktop mounting legs
  • Button inlay sticker sheets
  • USB-A cable
  • Hex keys
  • Quick start guide

Frequently asked questions

How does the landing gear lever work?

The multi-position landing gear lever has an all-metal internal mechanism and a spring-loaded lift-to-move gate, so you lift the lever before moving it, just like a real aircraft, preventing accidental actuation. A swappable detent plate sets it to 2-position (UP-DOWN) or 3-position (UP-OFF-DOWN) operation, and three gear status LEDs show in-transit and final gear position. It is read by a VPC Digital Contactless position sensor for precise, wear-free input.

Does the Control Panel #2 require a VIRPIL throttle or base?

No, the VPC Control Panel #2 operates as a completely standalone USB device. It connects directly to your PC and is recognised as a standard USB HID input device, working with any sim without any additional VIRPIL hardware. The AUX daisy chain feature is optional and adds extra functionality when used alongside a compatible VIRPIL throttle.

How does AUX daisy chaining work?

When connected via the AUX port to a compatible VIRPIL throttle or another Control Panel, both devices appear as a single combined USB input device. This means you can use the throttle's mode dial to trigger shift states across both devices, multiplying your effective input count without using additional USB ports on your PC.

Can I label the buttons?

Yes, each button has a transparent removable cap that lifts out to reveal a slot for a printed sticker inlay. Button inlay sticker sheets are included in the box with pre-made labels for common sim functions, and you can also print your own custom inlays to match your exact cockpit configuration.

What is the difference between the CP2 and CP1/CP3?

The Control Panel #2 is defined by its multi-position landing gear lever, gear status LEDs and high toggle-switch count, making it ideal for complex multi-role aircraft and airliners. The CP3 is built around four precision axis levers for throttle quadrant and multi-engine setups. The CP1 focuses on more buttons, flip covers and axis dials. All three share aircraft-grade Duralumin construction, RGB buttons and AUX daisy-chain connectivity.

What sims is this compatible with?

The VPC Control Panel #2 works with any sim that accepts USB controller input, including DCS World, Microsoft Flight Simulator 2024, X-Plane 12, IL-2 Sturmovik, Star Citizen and Elite Dangerous. It connects as a standard USB HID device, so no drivers are required.

Can I mount two Control Panels together?

Yes, two VPC Control Panels can be combined to form a single wider unit, or one can be attached alongside a VPC MongoosT-50CM2 throttle. Mounting hardware is available from VIRPIL for various configuration options, or you can use the included legs for standalone desktop placement.

What warranty and returns cover the Control Panel #2?

It's backed by a 2-year VIRPIL manufacturer warranty, handled locally by Player1 Sim Gear as the official Australian distributor, so there are no international returns for warranty work. You also get a 14-day change-of-mind return: item in original, unused condition with all packaging and accessories, refund less return shipping and a 5% handling fee. Full Australian Consumer Law protection applies. Call 0488 385 870 with any questions.

Do you ship to all of Australia? How long does delivery take?

Yes, we ship Australia-wide from our Queensland warehouse. Same-day or next business day dispatch. Delivery typically takes 2–8 business days depending on location. Call 0488 385 870 for current stock and express options.

Why buy from Player1 Sim Gear rather than directly from VIRPIL overseas?

Player1 Sim Gear is the official VIRPIL distributor for Australia and New Zealand. Buying locally means full Australian Consumer Law protection, a valid Australian GST tax invoice, warranty handled locally (no international shipping for repairs), Australian stock, and a team you can call on 0488 385 870 who actually flies sims like DCS and MSFS on this gear.
